Nominal pressure range: 210 bar
Maximum pressure limit: 280 bar
Working mode: open circuit
Available sizes: A10, A16, A22, A37, A45, A56, A70, A90, A100, A145
These specifications outline the capabilities of the YUKEN A piston pump range, ensuring reliable performance in a variety of applications.
1. High efficiency and quieter operation: Yuken A series piston pumps have excellent performance, with volumetric efficiency exceeding 98% and overall efficiency exceeding 90% at a pressure of 16 MPa (2320 PSI) and 1800 r/min. Its advanced design ensures reduced noise levels, providing a quieter operating environment.
2. Energy-saving design: Yuken A piston pump has high overall efficiency, which can significantly save energy and help achieve cost-effective operation.
3. Less heat: The pump power loss is low, which can minimize the increase in oil temperature, effectively reduce the requirements for fuel tank capacity, and improve system efficiency.
Check out the Yuken A-Series piston pumps from POOCCA Hydraulics Manufacturer โ including models A10FR01, A16-F-R-01, A22-F-R-01, A37-F-R-01, A56-F-R-01, A70-FR01, A90-FR01 and A145 -FR01. Take advantage of currently available discounted prices, fast delivery times, and unbeatable offers!
| Geometric Displacement cm3/rev | Minimum Adj. Flow cm3/rev | Operating Presure MPa (PSI) | Shaft Speed Range r/min | Approx. Mass kg (lbs.) | ||||
| Model Numbers | (cu. in. /rev) | (cu. in. /rev) | 2 | 1 | Max. | Min. | Flange Mtg. | Foot Mtg. |
| Rated | Intermittent | |||||||
| A10 | 10.0 (.610) | 2 (.122) | 16 (2320) | 21 (3050) | 1800 | 600 | 5.1 (11.2) | |
| A16 | 15.8 (.964) | 4 (.244) | 16 (2320) | 21 (3050) | 1800 | 600 | 16.5 (36.4) | 18.7 (41.2) |
| A22 | 22.2 (1.355) | 6 (.366) | 16 (2320) | 16 (2320) | 1800 | 600 | 16.5 (36.4) | 18.7 (41.2) |
| A37 | 36.9 (2.25) | 10 (.610) | 16 (2320) | 21 (3050) | 1800 | 600 | 28.0 (61.7) | 32.3 (71.2) |
| A45 | 45(2.75) | 11(.671) | 16 (2320) | 21 (3050) | 1800 | 600 | 28.0 (61.7) | 32.3 (71.2) |
| A56 | 56.2 (3.43) | 12 (.732) | 16 (2320) | 21 (3050) | 1800 | 600 | 35.0 (77.2) | 39.3 (86.7) |
| A70 | 70.0 (4.27) | 30 (1.83) | 25 (3630) | 28 (4060) | 1800 | 600 | 58.5 (129) | 70.5 (155) |
| A90 | 91.0 (5.55) | 56 (3.42) | 25 (3630) | 28 (4060) | 1800 | 600 | 72.5 (160) | 93 (205) |
| A100 | 100(6.1) | 62 (3.78) | 21 (3050) | 21 (3050) | 1800 | 600 | 72.5 (160) | 93 (205) |
| A145 | 145 (8.85) | 83 (5.06) | 25 (3630) | 28 (4060) | 1800 | 600 | 92.5 (204) | 117.5 (259) |
Yuken A Series piston pumps are designed for high performance applications requiring high pressure and flow. These pumps are axial piston pumps, which means they utilize a swashplate to create the reciprocating motion of the piston to deliver hydraulic oil. A-Series pumps are available in various displacement sizes from 12cc to 180cc and can operate at pressures up to 350 bar (5,000 psi).
One of the main advantages of the Yuken A-Series piston pumps is their high efficiency. These pumps are designed with high pressure to provide high flow rates while minimizing energy consumption. Also features low noise levels, making it suitable for applications where noise considerations are important.
Another advantage of the Yuken A-Series piston pumps is their reliability. These pumps are able to withstand harsh working conditions and are known for their durability. They feature sturdy construction using quality materials and components that are carefully selected and tested for durability and performance.
Q: When was POOCCA established?
Answer: POOCCA hydraulic manufacturer has been serving the hydraulic industry since its establishment in 1997 and has accumulated 26 years of valuable experience.
Q: What are the main products offered by POOCCA?
A: Our product range is extensive, covering 1,600 categories, with gear pumps, plunger pumps, vane pumps, motors, hydraulic accessories and hydraulic valves as our main products.
Q: How long does it take to receive the order?
A: Lead times for product delivery vary based on product type and availability. Typically, regular products can be delivered within 5-7 days, while special products may require additional time due to customization and quantity considerations.
Q: What is your product warranty policy?
A: We offer a 12-month comprehensive warranty on product quality.
Q: Where is your production facility located and what is your production capacity?
A: Our production facilities are strategically located in Guangdong, Jiangsu and Zhejiang provinces. The annual export volume reaches US$16 million, ensuring efficient production to meet market demand.
Q: What payment methods are accepted?
A: We provide a variety of convenient payment methods, including credit card, bank transfer, PayPal, etc. For larger orders, we require 30% advance payment and the remaining 70% to be cleared before shipment.
1. High efficiency and quieter operation: Yuken A series piston pumps have excellent performance, with volumetric efficiency exceeding 98% and overall efficiency exceeding 90% at a pressure of 16 MPa (2320 PSI) and 1800 r/min. Its advanced design ensures reduced noise levels, providing a quieter operating environment.
2. Energy-saving design: Yuken A piston pump has high overall efficiency, which can significantly save energy and help achieve cost-effective operation.
3. Less heat: The pump power loss is low, which can minimize the increase in oil temperature, effectively reduce the requirements for fuel tank capacity, and improve system efficiency.
Check out the Yuken A-Series piston pumps from POOCCA Hydraulics Manufacturer โ including models A10FR01, A16-F-R-01, A22-F-R-01, A37-F-R-01, A56-F-R-01, A70-FR01, A90-FR01 and A145 -FR01. Take advantage of currently available discounted prices, fast delivery times, and unbeatable offers!
| Geometric Displacement cm3/rev | Minimum Adj. Flow cm3/rev | Operating Presure MPa (PSI) | Shaft Speed Range r/min | Approx. Mass kg (lbs.) | ||||
| Model Numbers | (cu. in. /rev) | (cu. in. /rev) | 2 | 1 | Max. | Min. | Flange Mtg. | Foot Mtg. |
| Rated | Intermittent | |||||||
| A10 | 10.0 (.610) | 2 (.122) | 16 (2320) | 21 (3050) | 1800 | 600 | 5.1 (11.2) | |
| A16 | 15.8 (.964) | 4 (.244) | 16 (2320) | 21 (3050) | 1800 | 600 | 16.5 (36.4) | 18.7 (41.2) |
| A22 | 22.2 (1.355) | 6 (.366) | 16 (2320) | 16 (2320) | 1800 | 600 | 16.5 (36.4) | 18.7 (41.2) |
| A37 | 36.9 (2.25) | 10 (.610) | 16 (2320) | 21 (3050) | 1800 | 600 | 28.0 (61.7) | 32.3 (71.2) |
| A45 | 45(2.75) | 11(.671) | 16 (2320) | 21 (3050) | 1800 | 600 | 28.0 (61.7) | 32.3 (71.2) |
| A56 | 56.2 (3.43) | 12 (.732) | 16 (2320) | 21 (3050) | 1800 | 600 | 35.0 (77.2) | 39.3 (86.7) |
| A70 | 70.0 (4.27) | 30 (1.83) | 25 (3630) | 28 (4060) | 1800 | 600 | 58.5 (129) | 70.5 (155) |
| A90 | 91.0 (5.55) | 56 (3.42) | 25 (3630) | 28 (4060) | 1800 | 600 | 72.5 (160) | 93 (205) |
| A100 | 100(6.1) | 62 (3.78) | 21 (3050) | 21 (3050) | 1800 | 600 | 72.5 (160) | 93 (205) |
| A145 | 145 (8.85) | 83 (5.06) | 25 (3630) | 28 (4060) | 1800 | 600 | 92.5 (204) | 117.5 (259) |
Yuken A Series piston pumps are designed for high performance applications requiring high pressure and flow. These pumps are axial piston pumps, which means they utilize a swashplate to create the reciprocating motion of the piston to deliver hydraulic oil. A-Series pumps are available in various displacement sizes from 12cc to 180cc and can operate at pressures up to 350 bar (5,000 psi).
One of the main advantages of the Yuken A-Series piston pumps is their high efficiency. These pumps are designed with high pressure to provide high flow rates while minimizing energy consumption. Also features low noise levels, making it suitable for applications where noise considerations are important.
Another advantage of the Yuken A-Series piston pumps is their reliability. These pumps are able to withstand harsh working conditions and are known for their durability. They feature sturdy construction using quality materials and components that are carefully selected and tested for durability and performance.
Q: When was POOCCA established?
Answer: POOCCA hydraulic manufacturer has been serving the hydraulic industry since its establishment in 1997 and has accumulated 26 years of valuable experience.
Q: What are the main products offered by POOCCA?
A: Our product range is extensive, covering 1,600 categories, with gear pumps, plunger pumps, vane pumps, motors, hydraulic accessories and hydraulic valves as our main products.
Q: How long does it take to receive the order?
A: Lead times for product delivery vary based on product type and availability. Typically, regular products can be delivered within 5-7 days, while special products may require additional time due to customization and quantity considerations.
Q: What is your product warranty policy?
A: We offer a 12-month comprehensive warranty on product quality.
Q: Where is your production facility located and what is your production capacity?
A: Our production facilities are strategically located in Guangdong, Jiangsu and Zhejiang provinces. The annual export volume reaches US$16 million, ensuring efficient production to meet market demand.
Q: What payment methods are accepted?
A: We provide a variety of convenient payment methods, including credit card, bank transfer, PayPal, etc. For larger orders, we require 30% advance payment and the remaining 70% to be cleared before shipment.
POOCCA Hydraulics is a powerful hydraulic enterprise integrating R&D, manufacturing, sales and maintenance. Its products are exported to more than 120 countries. Its quality, price and service are deeply recognized and trusted by customers.
