High-pressure capability: Sunny HG2 hydraulic gear pumps are rated at 32 MPa, and the rugged design supports pressures up to 35 MPa for demanding applications.
Speed โโrange: Smooth operation from a minimum of 600 rpm to a maximum of 3000 rpm to meet a variety of requirements.
Dual pump combination options: HG gear pumps support the formation of a dual pump configuration, providing a flexible and efficient solution.
HG2-63,HG2-80,HG2-100,HG2-125,HG2-145,HG2-160
More related products are welcome for your consultation.
| Serial Number |
Specification | Displacement | Work pressure | Range of rotation | Weight (KG) |
||
| (ml/r) | Rated (Mpa) |
Highest (Mpa) |
Highest (r/min) |
Lowest (r/min) |
|||
| Sunny Gear Pump HG2 Internal Pumps | 63 | 64.7 | 31.5 | 35 | 3000 | 200 | 42 |
| 80 | 81.4 | 43 | |||||
| 100 | 100.2 | 45 | |||||
| 125 | 125.3 | 48 | |||||
| 145 | 145.2 | 25 | 28 | 50 | |||
| 160 | 162.8 | 21 | 26 | 52 | |||
Sunny gear pump axial and radial pressure compensation design: Ensures excellent volumetric efficiency, even when running at low speeds or low-viscosity fluids.
High-strength cast iron structure: Sunny HG gear pumps use an internal noise reduction design to effectively reduce operating noise.
Low flow and pressure pulsation: Maintains stable output even at low speeds, improving reliability.
HG series internal gear pumps in which the internal and external gears are precisely aligned on one side and separated by a unique “crescent plate” on the other side of the pump cover. The driving internal gear on the shaft ensures the coordinated rotation of the two gears.
At the inlet, when the gear is disengaged, negative pressure will be generated, which is beneficial to fluid suction. When engaged at the outlet, the gears continuously compress and pressurize the fluid for efficient discharge. This special design enables the pump to effectively handle fluids with viscosities ranging from 0.2 to 1000000cp.
HG2 gear pump is a fixed-displacement gap compensation type, which consists of a front cover, pump body, back cover, gear shaft, internal ring gear, sliding bearing, front and rear side plates, positioning rod, crescent plate, and crescent-shaped main plate. Additionally, it features a plastic rod for radial compensation, ensuring precise and reliable performance.
Suitable for industrial hydraulic machinery, including hydraulic systems in plastic machinery, shears, die-casting machinery, and forklift industries. The HG series is available in 0, 1, 2 model sizes and 10-80 component series with high pressure (32MPa) capability.
Features of 10-80 high pressure type (32MPa):
Innovative technology increases the efficiency of axial and radial pressures up to 30MPa.
Excellent wear resistance and strong service life.
Features an improved involute and short tooth internal mesh design to reduce pulsation and minimize noise.
Simple structure and easy maintenance.
Poocca Hydraulic Manufacturer focuses on comprehensive hydraulic services and specializes in the research and development, manufacturing, maintenance and sales of hydraulic products, including pumps, motors, valves and related parts.
POOCCA Hydraulics has been at the forefront of hydraulic innovation and development for more than two decades. We have won the trust of domestic and foreign customers and established strong corporate partnerships along the way. The annual export volume reaches US$16 million, and its products are sold to more than 100 countries around the world. We have established long-term and stable relationships with dealers in more than 75 countries, including major markets such as the United States, Indonesia, Mexico, Thailand, Russia, and Brazil.
At POOCCA, our greatest asset is our team of over 300 professionals. Among them, our dynamic sales team consists of 70 seasoned professionals who possess rich industry experience and deep insights into our domain.
| Serial Number |
Specification | Displacement | Work pressure | Range of rotation | Weight (KG) |
||
| (ml/r) | Rated (Mpa) |
Highest (Mpa) |
Highest (r/min) |
Lowest (r/min) |
|||
| Sunny Gear Pump HG2 Internal Pumps | 63 | 64.7 | 31.5 | 35 | 3000 | 200 | 42 |
| 80 | 81.4 | 43 | |||||
| 100 | 100.2 | 45 | |||||
| 125 | 125.3 | 48 | |||||
| 145 | 145.2 | 25 | 28 | 50 | |||
| 160 | 162.8 | 21 | 26 | 52 | |||
Sunny gear pump axial and radial pressure compensation design: Ensures excellent volumetric efficiency, even when running at low speeds or low-viscosity fluids.
High-strength cast iron structure: Sunny HG gear pumps use an internal noise reduction design to effectively reduce operating noise.
Low flow and pressure pulsation: Maintains stable output even at low speeds, improving reliability.
HG series internal gear pumps in which the internal and external gears are precisely aligned on one side and separated by a unique “crescent plate” on the other side of the pump cover. The driving internal gear on the shaft ensures the coordinated rotation of the two gears.
At the inlet, when the gear is disengaged, negative pressure will be generated, which is beneficial to fluid suction. When engaged at the outlet, the gears continuously compress and pressurize the fluid for efficient discharge. This special design enables the pump to effectively handle fluids with viscosities ranging from 0.2 to 1000000cp.
HG2 gear pump is a fixed-displacement gap compensation type, which consists of a front cover, pump body, back cover, gear shaft, internal ring gear, sliding bearing, front and rear side plates, positioning rod, crescent plate, and crescent-shaped main plate. Additionally, it features a plastic rod for radial compensation, ensuring precise and reliable performance.
Suitable for industrial hydraulic machinery, including hydraulic systems in plastic machinery, shears, die-casting machinery, and forklift industries. The HG series is available in 0, 1, 2 model sizes and 10-80 component series with high pressure (32MPa) capability.
Features of 10-80 high pressure type (32MPa):
Innovative technology increases the efficiency of axial and radial pressures up to 30MPa.
Excellent wear resistance and strong service life.
Features an improved involute and short tooth internal mesh design to reduce pulsation and minimize noise.
Simple structure and easy maintenance.
Poocca Hydraulic Manufacturer focuses on comprehensive hydraulic services and specializes in the research and development, manufacturing, maintenance and sales of hydraulic products, including pumps, motors, valves and related parts.
POOCCA Hydraulics has been at the forefront of hydraulic innovation and development for more than two decades. We have won the trust of domestic and foreign customers and established strong corporate partnerships along the way. The annual export volume reaches US$16 million, and its products are sold to more than 100 countries around the world. We have established long-term and stable relationships with dealers in more than 75 countries, including major markets such as the United States, Indonesia, Mexico, Thailand, Russia, and Brazil.
At POOCCA, our greatest asset is our team of over 300 professionals. Among them, our dynamic sales team consists of 70 seasoned professionals who possess rich industry experience and deep insights into our domain.
POOCCA Hydraulics is a powerful hydraulic enterprise integrating R&D, manufacturing, sales and maintenance. Its products are exported to more than 120 countries. Its quality, price and service are deeply recognized and trusted by customers.
