Salami 2PE gear pump series models cover 4.5, 6.5, 8.3, 11.3, 13.8, 16, 19, 22.5, 26, 10.5 and 12.5, each model adopts 12 teeth integral gear design, flange, shaft and port meet the main European and American standards. The back cover provides a variety of options and built-in valves to meet different application requirements.
The displacement range of 2PE gear pump products is from 4.6 cmยณ/rev to 12.7 cmยณ/rev, meeting the flow requirements of different working conditions. The maximum speed is as follows under different working conditions:
In P2 state, the maximum speed range is 4000 rpm to 3500 rpm.
In P1 state, the maximum speed range is 600 rpm to 500 rpm.
| GROUP 2 – E SERIES | cm3/rev | cu.in/rev | bar | psi | bar | psi | bar | psi | min-1 | |
| 2PE – 3.2* | 3.2 | 0.19 | 250 | 3625 | 280 | 4060 | 300 | 4350 | 4000 | 600 |
| 2PE – 3.9* | 3.9 | 0.24 | 250 | 3625 | 280 | 4060 | 300 | 4350 | 4000 | 600 |
| 2PE – 4.5 | 4.6 | 0.27 | 250 | 3625 | 280 | 4060 | 300 | 4350 | 4000 | 600 |
| 2PE – 6.5 | 6.5 | 0.4 | 250 | 3625 | 280 | 4060 | 300 | 4350 | 4000 | 600 |
| 2PE – 8.3 | 8.2 | 0.5 | 250 | 3625 | 280 | 4060 | 300 | 4350 | 3500 | 500 |
| 2PE – 10.5 | 10.6 | 0.65 | 250 | 3625 | 280 | 4060 | 300 | 4350 | 3500 | 500 |
| 2PE – 11.3 | 11.5 | 0.68 | 250 | 3625 | 280 | 4060 | 300 | 4350 | 3500 | 500 |
| 2PE – 12.5 | 12.7 | 0.77 | 250 | 3625 | 280 | 4060 | 300 | 4350 | 3500 | 500 |
| 2PE – 13.8 | 13.8 | 0.84 | 250 | 3625 | 280 | 4060 | 300 | 4350 | 3500 | 500 |
| 2PE – 16 | 16.6 | 1.01 | 250 | 3625 | 280 | 4060 | 300 | 4350 | 3000 | 400 |
| 2PE – 19 | 19.4 | 1.15 | 220 | 3190 | 240 | 3480 | 260 | 3750 | 3000 | 400 |
| 2PE – 22.5 | 22.9 | 1.37 | 200 | 2900 | 220 | 3190 | 240 | 3480 | 2750 | 400 |
| 2PE – 26 | 25.8 | 1.58 | 180 | 2610 | 200 | 2900 | 220 | 3190 | 2500 | 400 |
Salami 2PE series hydraulic components can support a variety of hydraulic fluids and are suitable for various industrial environments, ensuring that the system maintains efficient and stable operation under different temperature and pressure conditions.
HFB fluid: HFB fluid is an oil-in-water emulsion containing 40% water, suitable for use in relatively mild pressure environments. The maximum working pressure of this fluid is 130 bar (1880 psi), the maximum speed is 2500 rpm, and the operating temperature range is between 3ยฐC and 65ยฐC.
HFC fluid: HFC fluid is a water-glycol mixture suitable for medium and high pressure operations. The maximum working pressure of this fluid is 180 bar (2600 psi), the maximum speed is 1500 rpm, and the applicable temperature range is -20ยฐC to 65ยฐC, ensuring stability in low temperature environments.
HFD fluid: HFD fluid is a phosphate ester fluid suitable for high temperature conditions. Although its maximum working pressure is not specifically indicated, the maximum speed of this fluid is 1750 rpm and the applicable temperature range is -10ยฐC to 80ยฐC.
Salami2pe series hydraulic components ensure the excellent performance of the system in different environments according to the characteristics of different fluids and working conditions, meeting the diverse needs of customers.
Salami 2PE gear pump series models cover 4.5, 6.5, 8.3, 11.3, 13.8, 16, 19, 22.5, 26, 10.5 and 12.5, each model adopts 12 teeth integral gear design, flange, shaft and port meet the main European and American standards. The back cover provides a variety of options and built-in valves to meet different application requirements.
The displacement range of 2PE gear pump products is from 4.6 cmยณ/rev to 12.7 cmยณ/rev, meeting the flow requirements of different working conditions. The maximum speed is as follows under different working conditions:
In P2 state, the maximum speed range is 4000 rpm to 3500 rpm.
In P1 state, the maximum speed range is 600 rpm to 500 rpm.
| GROUP 2 – E SERIES | cm3/rev | cu.in/rev | bar | psi | bar | psi | bar | psi | min-1 | |
| 2PE – 3.2* | 3.2 | 0.19 | 250 | 3625 | 280 | 4060 | 300 | 4350 | 4000 | 600 |
| 2PE – 3.9* | 3.9 | 0.24 | 250 | 3625 | 280 | 4060 | 300 | 4350 | 4000 | 600 |
| 2PE – 4.5 | 4.6 | 0.27 | 250 | 3625 | 280 | 4060 | 300 | 4350 | 4000 | 600 |
| 2PE – 6.5 | 6.5 | 0.4 | 250 | 3625 | 280 | 4060 | 300 | 4350 | 4000 | 600 |
| 2PE – 8.3 | 8.2 | 0.5 | 250 | 3625 | 280 | 4060 | 300 | 4350 | 3500 | 500 |
| 2PE – 10.5 | 10.6 | 0.65 | 250 | 3625 | 280 | 4060 | 300 | 4350 | 3500 | 500 |
| 2PE – 11.3 | 11.5 | 0.68 | 250 | 3625 | 280 | 4060 | 300 | 4350 | 3500 | 500 |
| 2PE – 12.5 | 12.7 | 0.77 | 250 | 3625 | 280 | 4060 | 300 | 4350 | 3500 | 500 |
| 2PE – 13.8 | 13.8 | 0.84 | 250 | 3625 | 280 | 4060 | 300 | 4350 | 3500 | 500 |
| 2PE – 16 | 16.6 | 1.01 | 250 | 3625 | 280 | 4060 | 300 | 4350 | 3000 | 400 |
| 2PE – 19 | 19.4 | 1.15 | 220 | 3190 | 240 | 3480 | 260 | 3750 | 3000 | 400 |
| 2PE – 22.5 | 22.9 | 1.37 | 200 | 2900 | 220 | 3190 | 240 | 3480 | 2750 | 400 |
| 2PE – 26 | 25.8 | 1.58 | 180 | 2610 | 200 | 2900 | 220 | 3190 | 2500 | 400 |
Salami 2PE series hydraulic components can support a variety of hydraulic fluids and are suitable for various industrial environments, ensuring that the system maintains efficient and stable operation under different temperature and pressure conditions.
HFB fluid: HFB fluid is an oil-in-water emulsion containing 40% water, suitable for use in relatively mild pressure environments. The maximum working pressure of this fluid is 130 bar (1880 psi), the maximum speed is 2500 rpm, and the operating temperature range is between 3ยฐC and 65ยฐC.
HFC fluid: HFC fluid is a water-glycol mixture suitable for medium and high pressure operations. The maximum working pressure of this fluid is 180 bar (2600 psi), the maximum speed is 1500 rpm, and the applicable temperature range is -20ยฐC to 65ยฐC, ensuring stability in low temperature environments.
HFD fluid: HFD fluid is a phosphate ester fluid suitable for high temperature conditions. Although its maximum working pressure is not specifically indicated, the maximum speed of this fluid is 1750 rpm and the applicable temperature range is -10ยฐC to 80ยฐC.
Salami2pe series hydraulic components ensure the excellent performance of the system in different environments according to the characteristics of different fluids and working conditions, meeting the diverse needs of customers.
POOCCA Hydraulics is a powerful hydraulic enterprise integrating R&D, manufacturing, sales and maintenance. Its products are exported to more than 120 countries. Its quality, price and service are deeply recognized and trusted by customers.
