Displacement range: AZPFF hydraulic gear pump displacement generally ranges from 4 cmยณ/rev to 125 cmยณ/rev, depending on the model.
Maximum working pressure:
Continuous pressure: Usually up to 250 bar.
Intermittent pressure: Up to 280 bar.
Speed โโrange: Rexroth azpff pump is usually between 500 rpm and 3000 rpm, and the speed range of specific models is different.
Temperature range: The operating temperature of hydraulic oil is generally -10ยฐC to +80ยฐC.
Medium: Suitable for mineral oil and synthetic hydraulic oil, etc.
Interface form: It has a standard flange or threaded interface for easy installation.
High efficiency: Due to its compact design, the double gear pump has high volumetric efficiency and mechanical efficiency, suitable for long-term continuous operation.
Compact structure: The AZPFF double gear pump design can provide a larger flow output in a smaller space, saving equipment space.
High reliability: The use of high-quality materials and manufacturing processes, wear resistance, and long service life.
Modular design: Allows flexible configuration to adapt to different working conditions and application requirements.
Low noise: The optimized gear design reduces operating noise and is suitable for applications that require low noise.
High load capacity: Rexroth gear pump bearings and other important components are designed to be sturdy and can withstand large axial and radial loads.
Displacement range: AZPFF hydraulic gear pump displacement generally ranges from 4 cmยณ/rev to 125 cmยณ/rev, depending on the model.
Maximum working pressure:
Continuous pressure: Usually up to 250 bar.
Intermittent pressure: Up to 280 bar.
Speed โโrange: Rexroth azpff pump is usually between 500 rpm and 3000 rpm, and the speed range of specific models is different.
Temperature range: The operating temperature of hydraulic oil is generally -10ยฐC to +80ยฐC.
Medium: Suitable for mineral oil and synthetic hydraulic oil, etc.
Interface form: It has a standard flange or threaded interface for easy installation.
High efficiency: Due to its compact design, the double gear pump has high volumetric efficiency and mechanical efficiency, suitable for long-term continuous operation.
Compact structure: The AZPFF double gear pump design can provide a larger flow output in a smaller space, saving equipment space.
High reliability: The use of high-quality materials and manufacturing processes, wear resistance, and long service life.
Modular design: Allows flexible configuration to adapt to different working conditions and application requirements.
Low noise: The optimized gear design reduces operating noise and is suitable for applications that require low noise.
High load capacity: Rexroth gear pump bearings and other important components are designed to be sturdy and can withstand large axial and radial loads.
POOCCA Hydraulics is a powerful hydraulic enterprise integrating R&D, manufacturing, sales and maintenance. Its products are exported to more than 120 countries. Its quality, price and service are deeply recognized and trusted by customers.
