Pump Types and Controls
The Vickers PVE Series represents a range of direct shaft variable displacement pumps that offer adaptable performance through an advanced displacement control mechanism. These pumps are equipped with a pressure flow compensator/device to ensure efficient operation. A wide range of control options such as mobile pressure compensation, combined pressure and flow compensation and remote pressure control enhance their functionality and adaptability in different applications.
Design Features
PVE piston pumps feature a die-cast aluminum housing. This makes them particularly suitable for applications involving unsupported PTO drives. The aluminum housing not only minimizes the weight of the pump, but also provides excellent durability, ensuring reliable performance in a variety of challenging environments.
Displacement cm3/r (in3/r) | Rated Input | Maximum Pressure bar (psi) | |||
Model Code | Shaft End Pump | Cover End Pump | Speed | Shaft End | Cover End |
(At 0 psig Inlet) | |||||
PVE12 | 25 (1.54) | โ | 3000 | 207 (3000) | โ |
PVE19 | 41 (2.50) | โ | 2400 | 207 (3000) | โ |
PVE21 | 45 (2.75) | โ | 2400 | 186 (2700) | โ |
PVE41-25V40M (mobile) | 41 (2.50) | 40 (2.44) | 2400 | 207 (3000) | 207 (3000) |
PVE41-25V45M (mobile) | 41 (2.50) | 45 (2.75) | 2400 | 207 (3000) | 207 (3000) |
PVE41-25V55M (mobile) | 41 (2.50) | 55 (3.36) | 2400 | 207 (3000) | 207 (3000) |
PVE41-25V67M (mobile) | 41 (2.50) | 67 (4.09) | 2400 | 207 (3000) | 207 (3000) |
PVE45-25V40M (mobile) | 45 (2.75) | 40 (2.44) | 2400 | 186 (2700) | 207 (3000) |
PVE45-25V45M (mobile) | 45 (2.75) | 45 (2.75) | 2400 | 186 (2700) | 207 (3000) |
PVE45-25V55M (mobile) | 45 (2.75) | 55 (3.36) | 2400 | 186 (2700) | 207 (3000) |
PVE45-25V67M (mobile) | 45 (2.75) | 67 (4.09) | 2400 | 186 (2700) | 207 (3000) |
PVE41-25V40I (quieted) | 41 (2.50) | 40 (2.44) | 1800 | 207 (3000) | 172 (2500) |
PVE41-25V45I (quieted) | 41 (2.50) | 45 (2.75) | 1800 | 207 (3000) | 172 (2500) |
PVE41-25V55I (quieted) | 41 (2.50) | 55 (3.36) | 1800 | 207 (3000) | 172 (2500) |
PVE41-25V67I (quieted) | 41 (2.50) | 67 (4.09) | 1800 | 207 (3000) | 172 (2500) |
POOCCA Hydraulics (Shenzhen) Co., Ltd. focuses on providing comprehensive hydraulic solutions, including the research and development, manufacturing, maintenance and sales of hydraulic equipment such as pump, motor, valve and related components.
We have long-term partnerships with local dealers in more than 75 countries, mainly selling to major markets such as the United States, Indonesia, Mexico, Thailand, Russia and Brazil.
Our facilities include 2,000 square meters of office space and 8,000 square meters of factory, of which 6,000 square meters are dedicated to production. We are equipped with the most advanced manufacturing technology, including flexible machining centers and CNC gear grinders, ensuring the precision and quality of each product.
Utilizing advanced tools such as automatic gear detection systems and CAT fully computer-controlled testing machines, we provide comprehensive hydraulic solutions to meet the needs of different industries such as construction, agriculture, manufacturing, metallurgy, oil and material handling.
At POOCCA Hydraulics, we take great pride in our commitment to quality and safety, and our multiple certifications reflect our commitment to delivering products that meet the highest industry standards. We have obtained a number of utility model patents, ISO certification, FCC certification, CE certification, RoHS certification and other certificates.
Customization and Range of Applications
PVE pistpn pumps are highly versatile, offering a variety of configurations and customization options to meet specific application needs. Their adaptability makes them ideal for use in a wide range of industrial and commercial environments, from field operations to warehouse installations, providing reliable hydraulic solutions for a variety of needs.
