Parker TC motor series, with displacement ranging from 2.2 to 24.0 cubic inches per revolution.
Parker TC motors are capable of handling a maximum oil flow of 15 gallons per minute (gpm) for efficient operation and stable output. The maximum speed of the TC motor is 902 revolutions per minute (rpm).
Parker TC Series motor deliver high performance and durability in a compact footprint. Designed to excel in light-duty applications, TC motors ensure exceptional longevity even in limited space. Innovative design allows continuous flow of large volumes of fluid through splines and seals, helping to extend service life.
TC Series motors feature roller blades and a sealed commutation mechanism to ensure excellent volumetric efficiency and seamless low-speed operation. These motors offer great durability with their sintered copper/steel bushings capable of withstanding side loads up to 790 pounds.
Offering up to 2700 psi of torque and intermittent pressure up to 1750 psi, it’s designed to handle tough conditions with ease. The nominal shaft size is 1 inch, providing reliable performance and versatility for a variety of applications.
Motor | cm3/rev | cont / int* | cont / int* | max | cont / int* | max | cont / int* | |||||
Series | in3/rev | rev/min | l/min | bar | bar | Nm | KW | Nm | ||||
TC | g/min | psid | psig | lb-in | HP | lb-in | ||||||
TC 0036 | 36 | 902 | 34 | 34 | 86 | 121 | 134 | 31 | 44 | 4.2 | 16 | 27 |
2.2 | 9 | 9 | 1250 | 1750 | 1950 | 272 | 393 | 5.6 | 138 | 236 | ||
TC 0045 | 41 | 794 | 34 | 34 | 86 | 121 | 134 | 40 | 56 | 4.5 | 20 | 33 |
2.5 | 9 | 9 | 1250 | 1750 | 1950 | 351 | 496 | 6.1 | 174 | 295 | ||
TC 0050 | 49 | 688 | 34 | 34 | 86 | 121 | 134 | 48 | 67 | 4.7 | 27 | 39 |
3 | 9 | 9 | 1250 | 1750 | 1950 | 423 | 589 | 6.3 | 235 | 349 | ||
TC 0065 | 65 | 517 | 34 | 34 | 86 | 121 | 134 | 66 | 92 | 4.8 | 41 | 67 |
4 | 9 | 9 | 1250 | 1750 | 1950 | 582 | 810 | 6.5 | 361 | 590 | ||
TC 0080 | 82 | 413 | 34 | 34 | 86 | 121 | 134 | 96 | 119 | 4.9 | 61 | 86 |
5 | 9 | 9 | 1250 | 1750 | 1950 | 753 | 1050 | 6.6 | 539 | 758 | ||
TC 0100 | 98 | 460 | 45 | 45 | 86 | 121 | 134 | 100 | 140 | 6.1 | 78 | 106 |
6 | 12 | 12 | 1250 | 1750 | 1950 | 888 | 1240 | 8.2 | 691 | 934 | ||
TC 0130 | 130 | 429 | 45 | 57 | 86 | 121 | 134 | 138 | 192 | 7.5 | 111 | 169 |
8 | 12 | 15 | 1250 | 1750 | 1950 | 1218 | 1697 | 10.1 | 986 | 1492 | ||
TC 0165 | 163 | 346 | 45 | 57 | 86 | 121 | 134 | 173 | 238 | 7.5 | 139 | 209 |
10 | 12 | 15 | 1250 | 1750 | 1950 | 1529 | 2110 | 10 | 1232 | 1846 | ||
TC 0195 | 195 | 287 | 45 | 57 | 86 | 121 | 134 | 205 | 286 | 7.3 | 195 | 264 |
11.9 | 12 | 15 | 1250 | 1750 | 1950 | 1815 | 2532 | 9.8 | 1724 | 2332 | ||
TC 0230 | 228 | 246 | 45 | 57 | 76 | 107 | 134 | 215 | 298 | 6.3 | 195 | 261 |
13.9 | 12 | 15 | 1100 | 1550 | 1950 | 1905 | 2637 | 8.4 | 1722 | 2310 | ||
TC 0260 | 260 | 217 | 45 | 57 | 66 | 97 | 134 | 211 | 306 | 5.4 | 183 | 265 |
15.9 | 12 | 15 | 950 | 1400 | 1950 | 1870 | 2709 | 7.3 | 1618 | 2344 | ||
TC 0295 | 293 | 193 | 45 | 57 | 59 | 86 | 134 | 208 | 300 | 4.7 | 189 | 269 |
17.9 | 12 | 15 | 850 | 1250 | 1950 | 1843 | 2657 | 6.3 | 1675 | 2379 | ||
TC 0330 | 328 | 173 | 45 | 57 | 52 | 76 | 134 | 206 | 296 | 4 | 187 | 262 |
20 | 12 | 15 | 750 | 1100 | 1950 | 1819 | 2621 | 5.3 | 1655 | 2318 | ||
TC 0365 | 370 | 152 | 45 | 57 | 45 | 66 | 134 | 206 | 296 | 3.4 | 186 | 276 |
22.6 | 12 | 15 | 650 | 950 | 1950 | 1825 | 2622 | 4.6 | 1648 | 2443 | ||
TC 0390 | 392 | 144 | 45 | 57 | 45 | 66 | 134 | 207 | 296 | 3.2 | 192 | 286 |
24 | 12 | 15 | 650 | 950 | 1950 | 1832 | 2622 | 4.3 | 1698 | 2527 |
Parker TC motors are used in a wide range of industries. They are commonly used in industrial machinery such as presses, injection molding machines and mining equipment. In the field of mobile equipment, they play a vital role in construction, agricultural and material handling machinery. Additionally, in agriculture, TC motors increase the efficiency of tractors, combines and irrigation systems. Its powerful performance makes it an indispensable part of construction machinery such as concrete mixers and cranes. Additionally, in manufacturing, TC motors contribute to efficient power transmission and control in production lines and automation equipment.
