1. Through-Shaft Availability: The PAVC100 model is available with a through-shaft, providing additional flexibility for a variety of application requirements.
2. Integrated Intensifier: The PAVC piston pumps feature a built-in intensifier, which allows for high-speed operation up to 3000 RPM (2600 RPM for the PAVC100), increasing efficiency and productivity.
3. Sealed Bearings: These pumps feature sealed bearings, which increase reliability and service life, and minimize maintenance requirements.
4. Two-Piece Design: The two-piece design is easy to maintain, simplifying repairs and reducing downtime.
5. Field-Replaceable Cassette Controller: For added convenience, the cassette controller is field replaceable, ensuring fast, hassle-free maintenance. The replaceable bronze-plated port plate helps extend service life.
6. Standard Vent Feature: These pumps feature a standard vent feature for quick startup and optimized operating efficiency.
7. Inlet Pressure Sensitive Housing and Shaft Seals: The pump housing and shaft seals are only affected by the inlet pressure, contributing to efficient and reliable operation.
8. Maximum filter and cooling drain pressure: The maximum filter and/or cooling drain pressure is 7 bar (100 PSI) to ensure safety and optimal performance of the hydraulic system.
| Pump Model | Pump Delivery | Approx. Noise Levels dB(A) | ||||||||
| Displacement CM3/REV (IN3/REV) | @ 21 bar (300 PSI) in LPM (GPM) | @ Full Flow 1800 RPM (1200 RPM) | Input Power At 1800 RPM, Maximum | Operating Speed RPM (Maximum) | Pressure bar (PSI) Continuous (Maximum) | |||||
| 34 bar | 69 bar | 138 bar | 207 bar | Displacement & 207 bar (3000 PSI) | ||||||
| 1200 RPM | 1800 RPM | (500 PSI) | (1000 PSI) | (2000 PSI) | (3000 PSI) | |||||
| PAVC33 | 33 (2.0) | 39.4 (10.4) | 59.0 (15.6) | 75 (69) | 76 (72) | 78 (75) | 79 (77) | 21.3 kw (28.5 hp) | 3000 | 207 (3000) |
| PAVC38 | 38 (2.3) | 45.0 (11.9) | 67.8 (17.9) | 75 (69) | 76 (72) | 78 (75) | 79 (77) | 24.6 kw (33.0 hp) | 3000 | 207 (3000) |
| PAVC65 | 65 (4.0) | 78.7 (20.8) | 118.1 (31.2) | 77 (75) | 78 (76) | 80 (78) | 81 (79) | 43.1 kw (57.8 hp) | 3000 | 207 (3000) |
| PAVC100 | 100 (6.1) | 119.6 (31.6) | 179.8 (47.5) | 83 (77) | 82 (78) | 82 (79) | 85 (80) | 71.2 kw (95.5 hp) | 2600 | 207 (3000) |
Poocca is a comprehensive hydraulic service provider integrating the research and development, manufacturing, maintenance and sales of hydraulic pumps, motors and valves. Our expertise spans multiple industries including mining machinery, shipbuilding, engineering, power plants, injection molding, die casting machines and steel plants.
We focus on the renovation of hydraulic system projects, striving to reduce costs with localization and replace imported components. Our services include hydraulic system upgrades, optimization and energy efficiency enhancements.
Our product range includes:
Piston pump: A10VSO, A11VSO, A4VSO, A4VG, A7VO, PVH, PV series, etc.
Gear pump: AZPF, ALP, 1P, 0.25-0.5, PGP, SGP, HG series, etc.
Vane pump: VQ, T6T7, PV2R series, available in single pump, double pump and triple pump configurations.
Motor: A2FM, A2FE, A6VM, 2000 series, 6000 series, etc.
We prioritize meeting your needs promptly and efficiently. Ask us today and we’ll make sure you get exactly what you need for your hydraulic system.
1. Through-Shaft Availability: The PAVC100 model is available with a through-shaft, providing additional flexibility for a variety of application requirements.
2. Integrated Intensifier: The PAVC piston pumps feature a built-in intensifier, which allows for high-speed operation up to 3000 RPM (2600 RPM for the PAVC100), increasing efficiency and productivity.
3. Sealed Bearings: These pumps feature sealed bearings, which increase reliability and service life, and minimize maintenance requirements.
4. Two-Piece Design: The two-piece design is easy to maintain, simplifying repairs and reducing downtime.
5. Field-Replaceable Cassette Controller: For added convenience, the cassette controller is field replaceable, ensuring fast, hassle-free maintenance. The replaceable bronze-plated port plate helps extend service life.
6. Standard Vent Feature: These pumps feature a standard vent feature for quick startup and optimized operating efficiency.
7. Inlet Pressure Sensitive Housing and Shaft Seals: The pump housing and shaft seals are only affected by the inlet pressure, contributing to efficient and reliable operation.
8. Maximum filter and cooling drain pressure: The maximum filter and/or cooling drain pressure is 7 bar (100 PSI) to ensure safety and optimal performance of the hydraulic system.
| Pump Model | Pump Delivery | Approx. Noise Levels dB(A) | ||||||||
| Displacement CM3/REV (IN3/REV) | @ 21 bar (300 PSI) in LPM (GPM) | @ Full Flow 1800 RPM (1200 RPM) | Input Power At 1800 RPM, Maximum | Operating Speed RPM (Maximum) | Pressure bar (PSI) Continuous (Maximum) | |||||
| 34 bar | 69 bar | 138 bar | 207 bar | Displacement & 207 bar (3000 PSI) | ||||||
| 1200 RPM | 1800 RPM | (500 PSI) | (1000 PSI) | (2000 PSI) | (3000 PSI) | |||||
| PAVC33 | 33 (2.0) | 39.4 (10.4) | 59.0 (15.6) | 75 (69) | 76 (72) | 78 (75) | 79 (77) | 21.3 kw (28.5 hp) | 3000 | 207 (3000) |
| PAVC38 | 38 (2.3) | 45.0 (11.9) | 67.8 (17.9) | 75 (69) | 76 (72) | 78 (75) | 79 (77) | 24.6 kw (33.0 hp) | 3000 | 207 (3000) |
| PAVC65 | 65 (4.0) | 78.7 (20.8) | 118.1 (31.2) | 77 (75) | 78 (76) | 80 (78) | 81 (79) | 43.1 kw (57.8 hp) | 3000 | 207 (3000) |
| PAVC100 | 100 (6.1) | 119.6 (31.6) | 179.8 (47.5) | 83 (77) | 82 (78) | 82 (79) | 85 (80) | 71.2 kw (95.5 hp) | 2600 | 207 (3000) |
Poocca is a comprehensive hydraulic service provider integrating the research and development, manufacturing, maintenance and sales of hydraulic pumps, motors and valves. Our expertise spans multiple industries including mining machinery, shipbuilding, engineering, power plants, injection molding, die casting machines and steel plants.
We focus on the renovation of hydraulic system projects, striving to reduce costs with localization and replace imported components. Our services include hydraulic system upgrades, optimization and energy efficiency enhancements.
Our product range includes:
Piston pump: A10VSO, A11VSO, A4VSO, A4VG, A7VO, PVH, PV series, etc.
Gear pump: AZPF, ALP, 1P, 0.25-0.5, PGP, SGP, HG series, etc.
Vane pump: VQ, T6T7, PV2R series, available in single pump, double pump and triple pump configurations.
Motor: A2FM, A2FE, A6VM, 2000 series, 6000 series, etc.
We prioritize meeting your needs promptly and efficiently. Ask us today and we’ll make sure you get exactly what you need for your hydraulic system.
