Torque range: up to 370 kNm (up to 272,898 lb-ft)
Speed range: up to 125 rpm
Power range: up to 1000 kW
Maximum working pressure: 350 bar (5,076 psi)
Frame sizes: 280, 400, 560, 840 and 1120
Displacement: 15,100 to 70,400 cc/rev (921 to 4,296 in3/rev)
Specific torque: 240 to 1120 Nm/bar (12,204 to 56,952 ft-lbs/1,000 psi)
The CB axial hydraulic motor has high torque density and high energy efficiency, with flexible size design and minimal mechanical interfaces. It is insensitive to shock loads, has a very low moment of inertia, and occupies a small area to meet various application requirements. The through hole diameter is 110 mm.
Frame size | Nominal size | Specific | Displacement | Maximum | Maximum | Maximum | Maximum |
torque | torque 1) | speed | operating | operating | |||
pressure 2) | power 3) | ||||||
Nm/bar | cm3/rev | kNm | rpm | pย ย bar | kW | ||
CB 280 | 240 | 240 | 15100 | 79 | 68 | 350 | 530 |
280 | 280 | 17600 | 92 | 58 | 350 | 530 | |
CB 400 | 240 | 240 | 15100 | 79 | 125 5) | 350 | 970 |
280 | 280 | 17600 | 92 | 105 | 350 | 950 | |
320 | 320 | 20100 | 110 | 94 | 350 | 970 | |
360 | 360 | 22600 | 120 | 82 | 350 | 960 | |
400 | 400 | 25100 | 130 | 75 | 350 | 970 | |
440 | 440 | 27600 | 131 | 65 | 320 4) | 820 | |
480 | 480 | 30200 | 129 | 62 | 290 4) | 660 | |
520 | 520 | 32700 | 130 | 57 | 270 4) | 670 | |
560 | 560 | 35200 | 129 | 53 | 250 4) | 630 | |
CB 560 | 440 | 440 | 27600 | 140 | 65 | 350 | 930 |
480 | 480 | 30200 | 160 | 62 | 350 | 970 | |
520 | 520 | 32700 | 170 | 57 | 350 | 960 | |
560 | 560 | 35200 | 180 | 53 | 350 | 970 | |
CB 840 | 600 | 600 | 37700 | 200 | 45 | 350 | 880 |
640 | 640 | 40200 | 210 | 41 | 350 | 850 | |
680 | 680 | 42700 | 220 | 40 | 350 | 890 | |
720 | 720 | 45200 | 240 | 37 | 350 | 870 | |
760 | 760 | 47800 | 250 | 34 | 350 | 840 | |
800 | 800 | 50300 | 260 | 34 | 350 | 890 | |
840 | 840 | 52800 | 280 | 32 | 350 | 870 | |
CB 1120 | 880 | 880 | 55300 | 290 | 34 | 350 | 970 |
920 | 920 | 57800 | 300 | 33 | 350 | 980 | |
960 | 960 | 60300 | 315 | 32 | 350 | 990 | |
1000 | 1000 | 62800 | 330 | 31 | 350 | 1000 | |
1040 | 1040 | 65300 | 340 | 29 | 350 | 980 | |
1080 | 1080 | 67900 | 355 | 28 | 350 | 980 | |
1120 | 1120 | 70400 | 370 | 27 | 350 | 980 |
The Hรคgglunds CB series radial piston hydraulic motors offer excellent performance and are able to maintain at least 40,000 hours of operation in long continuous operation.
The Hรคgglunds CB hydraulic motor series is suitable for a wide range of heavy equipment such as crushers, feeders and roller mills. Its compact design and flexible mounting options make it an excellent choice in terms of space utilization.
The motors are available in a variety of sizes and displacements to optimize the drive system when selecting the motor and hydraulic pump combination. The hole design on the CB motor provides additional convenience in some specific applications such as drilling and boring.
The motors respond quickly and the rugged design enables them to withstand shock loads and shut down quickly when required. The Hรคgglunds CB hydraulic motor is indeed a rugged, economical and reliable drive solution.
Torque range: up to 370 kNm (up to 272,898 lb-ft)
Speed range: up to 125 rpm
Power range: up to 1000 kW
Maximum working pressure: 350 bar (5,076 psi)
Frame sizes: 280, 400, 560, 840 and 1120
Displacement: 15,100 to 70,400 cc/rev (921 to 4,296 in3/rev)
Specific torque: 240 to 1120 Nm/bar (12,204 to 56,952 ft-lbs/1,000 psi)
The CB axial hydraulic motor has high torque density and high energy efficiency, with flexible size design and minimal mechanical interfaces. It is insensitive to shock loads, has a very low moment of inertia, and occupies a small area to meet various application requirements. The through hole diameter is 110 mm.
Frame size | Nominal size | Specific | Displacement | Maximum | Maximum | Maximum | Maximum |
torque | torque 1) | speed | operating | operating | |||
pressure 2) | power 3) | ||||||
Nm/bar | cm3/rev | kNm | rpm | pย ย bar | kW | ||
CB 280 | 240 | 240 | 15100 | 79 | 68 | 350 | 530 |
280 | 280 | 17600 | 92 | 58 | 350 | 530 | |
CB 400 | 240 | 240 | 15100 | 79 | 125 5) | 350 | 970 |
280 | 280 | 17600 | 92 | 105 | 350 | 950 | |
320 | 320 | 20100 | 110 | 94 | 350 | 970 | |
360 | 360 | 22600 | 120 | 82 | 350 | 960 | |
400 | 400 | 25100 | 130 | 75 | 350 | 970 | |
440 | 440 | 27600 | 131 | 65 | 320 4) | 820 | |
480 | 480 | 30200 | 129 | 62 | 290 4) | 660 | |
520 | 520 | 32700 | 130 | 57 | 270 4) | 670 | |
560 | 560 | 35200 | 129 | 53 | 250 4) | 630 | |
CB 560 | 440 | 440 | 27600 | 140 | 65 | 350 | 930 |
480 | 480 | 30200 | 160 | 62 | 350 | 970 | |
520 | 520 | 32700 | 170 | 57 | 350 | 960 | |
560 | 560 | 35200 | 180 | 53 | 350 | 970 | |
CB 840 | 600 | 600 | 37700 | 200 | 45 | 350 | 880 |
640 | 640 | 40200 | 210 | 41 | 350 | 850 | |
680 | 680 | 42700 | 220 | 40 | 350 | 890 | |
720 | 720 | 45200 | 240 | 37 | 350 | 870 | |
760 | 760 | 47800 | 250 | 34 | 350 | 840 | |
800 | 800 | 50300 | 260 | 34 | 350 | 890 | |
840 | 840 | 52800 | 280 | 32 | 350 | 870 | |
CB 1120 | 880 | 880 | 55300 | 290 | 34 | 350 | 970 |
920 | 920 | 57800 | 300 | 33 | 350 | 980 | |
960 | 960 | 60300 | 315 | 32 | 350 | 990 | |
1000 | 1000 | 62800 | 330 | 31 | 350 | 1000 | |
1040 | 1040 | 65300 | 340 | 29 | 350 | 980 | |
1080 | 1080 | 67900 | 355 | 28 | 350 | 980 | |
1120 | 1120 | 70400 | 370 | 27 | 350 | 980 |
The Hรคgglunds CB series radial piston hydraulic motors offer excellent performance and are able to maintain at least 40,000 hours of operation in long continuous operation.
The Hรคgglunds CB hydraulic motor series is suitable for a wide range of heavy equipment such as crushers, feeders and roller mills. Its compact design and flexible mounting options make it an excellent choice in terms of space utilization.
The motors are available in a variety of sizes and displacements to optimize the drive system when selecting the motor and hydraulic pump combination. The hole design on the CB motor provides additional convenience in some specific applications such as drilling and boring.
The motors respond quickly and the rugged design enables them to withstand shock loads and shut down quickly when required. The Hรคgglunds CB hydraulic motor is indeed a rugged, economical and reliable drive solution.
