PVXS axial piston pumps with swash plate design have proven reliability and longevity, delivering unparalleled performance in a variety of industrial applications. Designed to perform in demanding conditions, the Vickers pump has exceptional features that make it stand out among similar pumps.
With a maximum pressure capability of up to 420 bar, PVXS pumps are designed to handle high-pressure environments with ease. Its rated speed of 1800 min-1 or higher ensures fast and efficient operation, making it ideal for applications requiring fast response and precise control.
One of the main highlights of the PVXS piston pump is its enlarged shaft and bearings for enhanced durability and longer service life. This rugged construction enables the pump to withstand long-term rigorous use, minimizing downtime and maintenance costs.
Additionally, the PVXS pump’s rotating and pressure-loaded components are carefully pressure-balanced to ensure smooth and stable performance even under challenging operating conditions. This feature helps reduce wear, further increasing pump reliability and service life.
For added convenience and versatility, integrated control pump, filter and safety valve options are available. This streamlined design not only simplifies installation but also optimizes space utilization, making it suitable for a wide range of applications in various industries.
The Vickers PVXS pumpโs innovative โcombo-blockโ design further extends its suitability, allowing it to be seamlessly adapted to different hydraulic systems and configurations. Whether in construction equipment, industrial machinery or mobile applications, PVXS piston pumps deliver consistent performance and reliability.
PVXS axial piston pumps feature fast response times, ensuring fast and precise control of hydraulic systems. This feature is critical for applications where rapid adjustment and accurate positioning are critical to operational efficiency and safety.
In summary, PVXS axial piston pumps redefine hydraulic system reliability, durability and performance. With their high-pressure capabilities, rugged construction, integrated features and versatile design, PVXS pumps set the standard for industry excellence.
| Model | ย PVXS 66 | ย PVXS 90 | ย PVXS 130 | ย PVXS 180 | ย PVXS 250 | ||
| Design | Swashplate – Axial piston pump | ||||||
| Type of mounting | Flange or foot-mounted. Combination units foot mounted only | ||||||
| Pipe connection Flange | |||||||
| ISO 6162-1 (SAE J518 code 61) | B | psi | P38M (1 1/2″ – 500) | P51M (2″ – 500) | P64M (2 1/2″ – 500) | P64M (2 1/2″ – 500) | P89M (3 1/2″ – 500) |
| ISO 6162-2 (SAE J518 code 62) | A | P25M (1″ – 6000) | P25M (1″ – 6000) | P25M (1″ – 6000) | P32M (1 1/4″ – 6000) | P32M (1 1/4″ – 6000) | |
| Direction of rotation | Clockwise, Counterclockwise on request | ||||||
| Mounting altitude | Horizontal, other mounting options are available on request | ||||||
| Ambient temperature range | Min | ยฐC | -20 | ||||
| Max | 50 | ||||||
| Weight | M | Kg | 55 | 75 | 106 | 114 | 212 |
| Moment of inertia | J | Kg m2 | 0.016 | 0.016 | 0.045 | 0.045 | 0.146 |
| Hydraulic characteristics | |||||||
| Rated pressure (100% duty cycle) | pN | bar | 350 | ||||
| Inlet pressure | p1min | bar | 0.85 abs 10 | 0.85 abs 10 | 0.95 abs 10 | 0.95 abs 10 | 1.0 abs 10 |
| p1max | |||||||
| Maximum pressure to ISO 5598:2008 | p2max | bar | 420 | ||||
| Hydraulic fluid | Hydraulic oil to DIN 51524 part 2. | ||||||
| See fluid recommendations in application data | |||||||
| Hydraulic fluid temperature range | min | ยฐC | -25 (on start up) | ||||
| max | 90 | ||||||
| Viscosity range for continuous operation | min | cSt | 10 | ||||
| max | 75 | ||||||
| Maximum permissible start viscosity | max | cSt | 1000 | ||||
| Cleanliness | ISO 4406 | 18/15/13 | |||||
| Maximum geometric displacement | Vg | cm3/rev | 66 | 90 | 130 | 180 | 250 |
| Speed range | nmin | rev/min | 150 | ||||
| nmax | 1800 | ||||||
| Case pressure (over pressure) n = 1200 rev/min | pcase | bar | |||||
| 3.5 | 3.5 | 3.2 | 3.2 | 2.8 | |||
| n = 1500 rev/min | 2.7 | 2.7 | 2.5 | 2.5 | 2.1 | ||
| n = 1800 rev/min | 2.2 | 2.2 | 2 | 2 | 1.7 | ||
Some full models, if you don’t find the model you want, welcome to send your request to poocca hydraulic manufacturer, we will provide you with preferential prices and high-quality products as soon as possible.
| PVXS-066M02R0001R01SV0ADF000A0F0010 | PVXS-090M02R00A1R01SV0ALR000A3K0220 | PVXS-130-M-R-SP-0000-00 |
| PVXS-066-M-R-DF-0000-000 (806052041704) | PVXS-090-M-R-DF-0000-000 | PVXS-130M-04R001R01SVVADF |
| PVXS-090M02R0001A01SV0ADF000A0010 | PVXS-090-M-R-SP-0000-344 | PVXS-180-M-R-DF-0000-000 (060007113CH ) |
| PVXS-090M02R0001R01SV0ADF000A0010 | PVXS-130M-04R001R01SVVADF | PVXS-250M06R0001R01SVVADF000A0 |
| PVXS-090M02R0001R01SVVADF | PVXS-130-M-R-DF-0000-000 | PVXS-250-M-R-DF-0000-000 |
