Auxiliary valve functions: including overflow valve, anti-cavitation valve, combination valve, etc. (not applicable to DCV40-45 models).
Control type: DCV hydraulic valve supports a variety of operation modes, such as manual, joystick control, cable control, pneumatic, electromagnetic, electric-pneumatic, electro-hydraulic control, etc.
DCV series hydraulic valves, flow range 20-200 l/min, pressure up to 350 bar, models include DCV20 to DCV200
Structural form: integral or segmented design can be selected.
Transmission port of DCV hydraulic valve: can be used as the hydraulic power source of other components.
| Model | DCV20 | DCV40 | DCV45 | DCV60 | DCV100 | DCV140 | DCV200 |
| Nominal low rate (l/min) | 20 | 40 | 45 | 60 | 100 | 140 | 200 |
| Max. pressure (bar) | 350 | 350 | 350 | 350 | 350 | 350 | 350 |
| Operating range (mm2/s) | 15~75 | 15~75 | 15~75 | 15~75 | 15~75 | 15~75 | 15~75 |
| Viscosity (mm2/s) Minimum | 12 | 12 | 12 | 12 | 12 | 12 | 12 |
| Maximum | 400 | 400 | 400 | 400 | 400 | 400 | 400 |
| Ambient temperature range (ยฐC) | -40~80 | -40~80 | -40~80 | -40~80 | -40~80 | -40~80 | -40~80 |
| Structure – Monoblock | 6 sections | 1~8 sections | 1~8 sections | 1~12 sections | 1~12 sections | 1~12 sections | 1~12 sections |
DCV directional control valve is designed for high pressure hydraulic system such as drilling rig, sanitary equipment, etc.
Auxiliary valve functions: including overflow valve, anti-cavitation valve, combination valve, etc. (not applicable to DCV40-45 models).
Control type: DCV hydraulic valve supports a variety of operation modes, such as manual, joystick control, cable control, pneumatic, electromagnetic, electric-pneumatic, electro-hydraulic control, etc.
DCV series hydraulic valves, flow range 20-200 l/min, pressure up to 350 bar, models include DCV20 to DCV200
Structural form: integral or segmented design can be selected.
Transmission port of DCV hydraulic valve: can be used as the hydraulic power source of other components.
| Model | DCV20 | DCV40 | DCV45 | DCV60 | DCV100 | DCV140 | DCV200 |
| Nominal low rate (l/min) | 20 | 40 | 45 | 60 | 100 | 140 | 200 |
| Max. pressure (bar) | 350 | 350 | 350 | 350 | 350 | 350 | 350 |
| Operating range (mm2/s) | 15~75 | 15~75 | 15~75 | 15~75 | 15~75 | 15~75 | 15~75 |
| Viscosity (mm2/s) Minimum | 12 | 12 | 12 | 12 | 12 | 12 | 12 |
| Maximum | 400 | 400 | 400 | 400 | 400 | 400 | 400 |
| Ambient temperature range (ยฐC) | -40~80 | -40~80 | -40~80 | -40~80 | -40~80 | -40~80 | -40~80 |
| Structure – Monoblock | 6 sections | 1~8 sections | 1~8 sections | 1~12 sections | 1~12 sections | 1~12 sections | 1~12 sections |
DCV directional control valve is designed for high pressure hydraulic system such as drilling rig, sanitary equipment, etc.
