Danfoss D1 series variable displacement axial piston pumps are designed for open circuit hydraulic systems in heavy mobile equipment.
Displacement range: 65 โ 260 cmยณ
Speed โโlimit: 2500 rpm
Maximum operating pressure: 350 bar
Peak pressure: up to 400 bar
The Danfoss D1 expands Danfoss open circuit pump portfolio, providing customers with greater choice in hydraulic power products. It is designed to work seamlessly with the new PVG 128/256 high flow valve, providing OEMs with a complete hydraulic system portfolio.
The D1 hydraulic piston pump offers four displacement options (130cc-260cc), various control options (pressure, load sensing, power limiting and displacement control), continuous output pressures up to 350bar [5000psi], intermittent output pressures up to 400bar [5802psi], and an integrated oil charge pump that enables the D1 pump to operate at speeds up to 2500rpm.
Danfoss D1 hydraulic piston pumps are designed for quality and reliability
Proven and optimized 9-piston rotary assembly
Slanted bore cylinder block design improves self-priming capabilities
Spherical valve plate and cylinder block surface provide stable rotation for high efficiency
| Features |
Unit |
D1P 130 Pump | D1P 145 Pump | D1P 193 Pump | D1P 260 Pump | |||
| W/Oย Charge Pump | W/ Charge Pump | W/Oย Charge Pump | W/ Charge Pump | W/Charge Pump | W/Charge Pump | |||
| Displacement | cm3ย [in3] | 130ย [7.93] | 130ย [7.93] | 145ย [8.85] | 145ย [8.85] | 193ย [11.78] | 260ย [15.87] | |
| Availableย Rotation1 | CCWย [L] | |||||||
| CWย [R] | ||||||||
| Weightย (approx.) | kgย [lbs] | 68ย [150] | 74ย [163] | 68ย [150] | 74ย [163] | 106ย [234] | 141ย [311] | |
| Input ย ย Speed | Min. |
rpm |
500 | 500 | 500 | 500 | 500 | 500 |
| Rated | 2200 | 2500 | 2200 | 2500 | 2500 | 2300 | ||
| Max. | 2500 | 2500 | 2200 | 2500 | 2500 | 2300 | ||
| Theoretical Flow | l/min
[USgal/ min] |
273ย [72] | 325ย [86] | 319ย [84] | 363ย [96] | 483ย [128] | 598ย [158] | |
| Systemย ย ย Pressure | Max. Workingย Pressure2 |
barย [psi] |
350ย [5076] | |||||
| Max.ย Pressure | 400ย [5802] | |||||||
| Inlet
Pressureย (Abs) |
Min. | barย [psi] | 0.8ย [11.6] | 0.6ย [8.7] | 0.8ย [11.6] | 0.6ย [8.7] | 0.6ย [8.7] | 0.6ย [8.7] |
| Max. | 30ย [435] | 2ย [29] | 30ย [435] | 2ย [29] | 2ย [29] | 2ย [29] | ||
| Case
Pressureย (Abs) |
Max. |
barย [psi] |
2ย [29] |
|||||
At Poocca, customization is at the heart of what we do. From custom model specifications to personalized logos and packaging, we offer a full range of customization options to meet your unique needs. Our team of professionals work closely with you to experience Poocca customization.
Poocca is a leading hydraulic manufacturer with over 20 years of industry expertise. With stable partnerships in multiple countries, we have won unanimous praise for our competitive prices and excellent quality. Our commitment to excellence ensures customers around the world trust us to meet their hydraulic needs. Whether it’s reliability, performance or innovation, Poocca delivers reliable solutions that exceed expectations. Choose Poocca for hydraulic solutions you can trust.
The new D1 pump is a high-pressure, high-performance variable axial piston pump developed for open circuit systems in the most extreme application environments. Its robust design makes it an ideal solution for concrete machines, mining machines, cranes, drilling machines, offshore, marine and oil and gas equipment.
The Danfoss D1 expands Danfoss open circuit pump portfolio, providing customers with greater choice in hydraulic power products. It is designed to work seamlessly with the new PVG 128/256 high flow valve, providing OEMs with a complete hydraulic system portfolio.
The D1 hydraulic piston pump offers four displacement options (130cc-260cc), various control options (pressure, load sensing, power limiting and displacement control), continuous output pressures up to 350bar [5000psi], intermittent output pressures up to 400bar [5802psi], and an integrated oil charge pump that enables the D1 pump to operate at speeds up to 2500rpm.
Danfoss D1 hydraulic piston pumps are designed for quality and reliability
Proven and optimized 9-piston rotary assembly
Slanted bore cylinder block design improves self-priming capabilities
Spherical valve plate and cylinder block surface provide stable rotation for high efficiency
| Features |
Unit |
D1P 130 Pump | D1P 145 Pump | D1P 193 Pump | D1P 260 Pump | |||
| W/Oย Charge Pump | W/ Charge Pump | W/Oย Charge Pump | W/ Charge Pump | W/Charge Pump | W/Charge Pump | |||
| Displacement | cm3ย [in3] | 130ย [7.93] | 130ย [7.93] | 145ย [8.85] | 145ย [8.85] | 193ย [11.78] | 260ย [15.87] | |
| Availableย Rotation1 | CCWย [L] | |||||||
| CWย [R] | ||||||||
| Weightย (approx.) | kgย [lbs] | 68ย [150] | 74ย [163] | 68ย [150] | 74ย [163] | 106ย [234] | 141ย [311] | |
| Input ย ย Speed | Min. |
rpm |
500 | 500 | 500 | 500 | 500 | 500 |
| Rated | 2200 | 2500 | 2200 | 2500 | 2500 | 2300 | ||
| Max. | 2500 | 2500 | 2200 | 2500 | 2500 | 2300 | ||
| Theoretical Flow | l/min
[USgal/ min] |
273ย [72] | 325ย [86] | 319ย [84] | 363ย [96] | 483ย [128] | 598ย [158] | |
| Systemย ย ย Pressure | Max. Workingย Pressure2 |
barย [psi] |
350ย [5076] | |||||
| Max.ย Pressure | 400ย [5802] | |||||||
| Inlet
Pressureย (Abs) |
Min. | barย [psi] | 0.8ย [11.6] | 0.6ย [8.7] | 0.8ย [11.6] | 0.6ย [8.7] | 0.6ย [8.7] | 0.6ย [8.7] |
| Max. | 30ย [435] | 2ย [29] | 30ย [435] | 2ย [29] | 2ย [29] | 2ย [29] | ||
| Case
Pressureย (Abs) |
Max. |
barย [psi] |
2ย [29] |
|||||
At Poocca, customization is at the heart of what we do. From custom model specifications to personalized logos and packaging, we offer a full range of customization options to meet your unique needs. Our team of professionals work closely with you to experience Poocca customization.
Poocca is a leading hydraulic manufacturer with over 20 years of industry expertise. With stable partnerships in multiple countries, we have won unanimous praise for our competitive prices and excellent quality. Our commitment to excellence ensures customers around the world trust us to meet their hydraulic needs. Whether it’s reliability, performance or innovation, Poocca delivers reliable solutions that exceed expectations. Choose Poocca for hydraulic solutions you can trust.
The new D1 pump is a high-pressure, high-performance variable axial piston pump developed for open circuit systems in the most extreme application environments. Its robust design makes it an ideal solution for concrete machines, mining machines, cranes, drilling machines, offshore, marine and oil and gas equipment.
