Casappa PLM PLP Gear Pump Motor Nominal Pressure:250 bar
Maximum Pressure:280 bar
Operation Mode:External Gear Motor
PLM PLP hydraulic motor displacement:1.07 1.6 2.13 2.67 3.34 4.27 5.34 6.2 6.67 8.51 10.67 4.95 6.61 7.29 8.26 9.17 10.9 11.23 14.53 16.85 19.09 21.14 24.84 26.42 28.21 33.03 21.99 26.7 34.55 39.27 43.98 51.83 61.26 73.82 81.68 91.1cc/rev
Lightweight Design:
PLP PLM pump motors feature SAE and European mounting flanges
Cast iron and aluminum rear covers reduce weight without sacrificing performance
Efficient Performance:
Extruded aluminum body houses single-piece gear, journal and shaft assemblies
Pressure balance system ensures excellent volumetric and overall efficiency
Maximum peak pressures up to 4350 psi (300 bar)
Maximum speeds up to 4000 min-1
Durability:
Oversized bearings extend life even at high pressures
Casappa hydraulic pumps consist of a three-piece gear pump and motor, with an extruded body made from high-strength aluminum alloy
Various Options:
Drive shaft options include spline, parallel key and tapered versions, and PLP gear pumps and PLM motors meet all SAE and European standards
Displacements range from 0.07 in./rev (1.07 cc/rev) to 5.56 in./rev (91.10 cc/rev)
Available in 10, 20 and 30 Group
Efficient Operation:
High operating efficiency, with integrated outboard bearings, suitable for heavy-duty applications
Flexible Application:
Standard version with a wide range of units to choose from
Common inlet and independent stages available
Capable of supporting electro-hydraulic fan drive systems
Designs can be customised to meet specific requirements
These features make Casappa PLM PLP pumps and motors a popular choice for customers
| Series | Pump type PLP Motor type PLM |
Displacement | Max. pressure | Max. speed |
Max. speed |
||
| p1 | p2 | p3 | |||||
| in3/rev (cm3/rev) |
psi (bar) | min -1 | |||||
| 10 | PL. 10•1 | 0.07 (1,07) | 3770 (260) | 4060 (280) | 4205 (290) | 4000 | 650 |
| PL. 10•1,5 | 0.10 (1,6) | 3770 (260) | 4060 (280) | 4205 (290) | 4000 | 650 | |
| PL. 10•2 | 0.13 (2,13) | 3770 (260) | 4060 (280) | 4205 (290) | 4000 | 650 | |
| PL. 10•2,5 | 0.16 (2,67) | 3770 (260) | 4060 (280) | 4205 (290) | 4000 | 650 | |
| PL. 10•3,15 | 0.20 (3,34) | 3770 (260) | 4060 (280) | 4205 (290) | 4000 | 650 | |
| PL. 10•4 | 0.26 (4,27) | 3625 (250) | 3915 (270) | 4060 (280) | 4000 | 650 | |
| PL. 10•5 | 0.33 (5,34) | 3625 (250) | 3915 (270) | 4060 (280) | 4000 | 650 | |
| PL. 10•5,8 | 0.38 (6,20) | 3335 (230) | 3625 (250) | 3770 (260) | 3500 | 650 | |
| PL. 10•6,3 | 0.41 (6,67) | 3335 (230) | 3625 (250) | 3770 (260) | 3500 | 650 | |
| PL. 10•8 | 0.52 (8,51) | 2610 (180) | 2900 (200) | 3045 (210) | 3500 | 650 | |
| PL. 10•10 | 0.65 (10,67) | 2030 (140) | 2320 (160) | 2465 (170) | 3500 | 650 | |
| 20 | PL. 20•4 | 0.30 (4,95) | 3625 (250) | 4060 (280) | 4350 (300) | 4000 | 600 |
| PL. 20•6,3 | 0.40 (6,61) | 3625 (250) | 4060 (280) | 4350 (300) | 4000 | 600 | |
| PL. 20•7,2 | 0,44 (7,29) | 3625 (250) | 4060 (280) | 4350 (300) | 4000 | 600 | |
| PL. 20•8 | 0.50 (8,26) | 3625 (250) | 4060 (280) | 4350 (300) | 3500 | 600 | |
| PL. 20•9 | 0.56 (9,17) | 3625 (250) | 4060 (280) | 4350 (300) | 3500 | 600 | |
| PL. 20•10,5 | 0.66 (10,9) | 3625 (250) | 4060 (280) | 4350 (300) | 3500 | 600 | |
| PL. 20•11,2 | 0.69 (11,23) | 3625 (250) | 4060 (280) | 4350 (300) | 3500 | 600 | |
| PL. 20•14 | 0.89 (14,53) | 3625 (250) | 4060 (280) | 4350 (300) | 3500 | 500 | |
| PL. 20•16 | 1.03 (16,85) | 3625 (250) | 4060 (280) | 4350 (300) | 3000 | 500 | |
| PL. 20•19 | 1.16 (19,09) | 2900 (200) | 3190 (220) | 3480 (240) | 3000 | 500 | |
| PL. 20•20 | 1.29 (21,14) | 2900 (200) | 3190 (220) | 3480 (240) | 3000 | 500 | |
| PL. 20•24,5 | 1.52 (24,84) | 2465 (170) | 2755 (190) | 3045 (210) | 2500 | 500 | |
| PL. 20•25 | 1.61 (26,42) | 2465 (170) | 2755 (190) | 3045 (210) | 2500 | 500 | |
| PL. 20•27,8 | 1.72 (28,21) | 1885 (130) | 2175 (150) | 2465 (170) | 2000 | 500 | |
| PL. 20•31,5 | 2.01 (33,03) | 1885 (130) | 2175 (150) | 2465 (170) | 2000 | 500 | |
| 30 | PL. 30•22 | 1.34 (21,99) | 3625 (250) | 3915 (270) | 4060 (280) | 3000 | 350 |
| PL. 30•27 | 1.63 (26,70) | 3625 (250) | 3915 (270) | 4060 (280) | 3000 | 350 | |
| PL. 30•34 | 2.11 (34,55) | 3480 (240) | 3770 (260) | 3915 (270) | 3000 | 350 | |
| PL. 30•38 | 2.40 (39,27) | 3480 (240) | 3770 (260) | 3915 (270) | 3000 | 350 | |
| PL. 30•43 | 2.68 (43,98) | 3335 (230) | 3625 (250) | 3770 (260) | 3000 | 350 | |
| PL. 30•51 | 3.16 (51,83) | 3045 (210) | 3335 (230) | 3480 (240) | 2500 | 350 | |
| PL. 30•61 | 3.74 (61,26) | 2755 (190) | 3045 (210) | 3190 (220) | 2500 | 350 | |
| PL. 30•73 | 4.50 (73,82) | 2465 (170) | 2755 (190) | 2900 (200) | 2500 | 350 | |
| PL. 30•82 | 4.98 (81,68) | 2320 (160) | 2465 (170) | 2610 (180) | 2200 | 350 | |
| PL. 30•90 | 5.56 (91,10) | 2175 (150) | 2320 (160) | 2465 (170) | 2200 | 350 | |
Lightweight Design:
PLP PLM pump motors feature SAE and European mounting flanges
Cast iron and aluminum rear covers reduce weight without sacrificing performance
Efficient Performance:
Extruded aluminum body houses single-piece gear, journal and shaft assemblies
Pressure balance system ensures excellent volumetric and overall efficiency
Maximum peak pressures up to 4350 psi (300 bar)
Maximum speeds up to 4000 min-1
Durability:
Oversized bearings extend life even at high pressures
Casappa hydraulic pumps consist of a three-piece gear pump and motor, with an extruded body made from high-strength aluminum alloy
Various Options:
Drive shaft options include spline, parallel key and tapered versions, and PLP gear pumps and PLM motors meet all SAE and European standards
Displacements range from 0.07 in./rev (1.07 cc/rev) to 5.56 in./rev (91.10 cc/rev)
Available in 10, 20 and 30 Group
Efficient Operation:
High operating efficiency, with integrated outboard bearings, suitable for heavy-duty applications
Flexible Application:
Standard version with a wide range of units to choose from
Common inlet and independent stages available
Capable of supporting electro-hydraulic fan drive systems
Designs can be customised to meet specific requirements
These features make Casappa PLM PLP pumps and motors a popular choice for customers
| Series | Pump type PLP Motor type PLM |
Displacement | Max. pressure | Max. speed |
Max. speed |
||
| p1 | p2 | p3 | |||||
| in3/rev (cm3/rev) |
psi (bar) | min -1 | |||||
| 10 | PL. 10•1 | 0.07 (1,07) | 3770 (260) | 4060 (280) | 4205 (290) | 4000 | 650 |
| PL. 10•1,5 | 0.10 (1,6) | 3770 (260) | 4060 (280) | 4205 (290) | 4000 | 650 | |
| PL. 10•2 | 0.13 (2,13) | 3770 (260) | 4060 (280) | 4205 (290) | 4000 | 650 | |
| PL. 10•2,5 | 0.16 (2,67) | 3770 (260) | 4060 (280) | 4205 (290) | 4000 | 650 | |
| PL. 10•3,15 | 0.20 (3,34) | 3770 (260) | 4060 (280) | 4205 (290) | 4000 | 650 | |
| PL. 10•4 | 0.26 (4,27) | 3625 (250) | 3915 (270) | 4060 (280) | 4000 | 650 | |
| PL. 10•5 | 0.33 (5,34) | 3625 (250) | 3915 (270) | 4060 (280) | 4000 | 650 | |
| PL. 10•5,8 | 0.38 (6,20) | 3335 (230) | 3625 (250) | 3770 (260) | 3500 | 650 | |
| PL. 10•6,3 | 0.41 (6,67) | 3335 (230) | 3625 (250) | 3770 (260) | 3500 | 650 | |
| PL. 10•8 | 0.52 (8,51) | 2610 (180) | 2900 (200) | 3045 (210) | 3500 | 650 | |
| PL. 10•10 | 0.65 (10,67) | 2030 (140) | 2320 (160) | 2465 (170) | 3500 | 650 | |
| 20 | PL. 20•4 | 0.30 (4,95) | 3625 (250) | 4060 (280) | 4350 (300) | 4000 | 600 |
| PL. 20•6,3 | 0.40 (6,61) | 3625 (250) | 4060 (280) | 4350 (300) | 4000 | 600 | |
| PL. 20•7,2 | 0,44 (7,29) | 3625 (250) | 4060 (280) | 4350 (300) | 4000 | 600 | |
| PL. 20•8 | 0.50 (8,26) | 3625 (250) | 4060 (280) | 4350 (300) | 3500 | 600 | |
| PL. 20•9 | 0.56 (9,17) | 3625 (250) | 4060 (280) | 4350 (300) | 3500 | 600 | |
| PL. 20•10,5 | 0.66 (10,9) | 3625 (250) | 4060 (280) | 4350 (300) | 3500 | 600 | |
| PL. 20•11,2 | 0.69 (11,23) | 3625 (250) | 4060 (280) | 4350 (300) | 3500 | 600 | |
| PL. 20•14 | 0.89 (14,53) | 3625 (250) | 4060 (280) | 4350 (300) | 3500 | 500 | |
| PL. 20•16 | 1.03 (16,85) | 3625 (250) | 4060 (280) | 4350 (300) | 3000 | 500 | |
| PL. 20•19 | 1.16 (19,09) | 2900 (200) | 3190 (220) | 3480 (240) | 3000 | 500 | |
| PL. 20•20 | 1.29 (21,14) | 2900 (200) | 3190 (220) | 3480 (240) | 3000 | 500 | |
| PL. 20•24,5 | 1.52 (24,84) | 2465 (170) | 2755 (190) | 3045 (210) | 2500 | 500 | |
| PL. 20•25 | 1.61 (26,42) | 2465 (170) | 2755 (190) | 3045 (210) | 2500 | 500 | |
| PL. 20•27,8 | 1.72 (28,21) | 1885 (130) | 2175 (150) | 2465 (170) | 2000 | 500 | |
| PL. 20•31,5 | 2.01 (33,03) | 1885 (130) | 2175 (150) | 2465 (170) | 2000 | 500 | |
| 30 | PL. 30•22 | 1.34 (21,99) | 3625 (250) | 3915 (270) | 4060 (280) | 3000 | 350 |
| PL. 30•27 | 1.63 (26,70) | 3625 (250) | 3915 (270) | 4060 (280) | 3000 | 350 | |
| PL. 30•34 | 2.11 (34,55) | 3480 (240) | 3770 (260) | 3915 (270) | 3000 | 350 | |
| PL. 30•38 | 2.40 (39,27) | 3480 (240) | 3770 (260) | 3915 (270) | 3000 | 350 | |
| PL. 30•43 | 2.68 (43,98) | 3335 (230) | 3625 (250) | 3770 (260) | 3000 | 350 | |
| PL. 30•51 | 3.16 (51,83) | 3045 (210) | 3335 (230) | 3480 (240) | 2500 | 350 | |
| PL. 30•61 | 3.74 (61,26) | 2755 (190) | 3045 (210) | 3190 (220) | 2500 | 350 | |
| PL. 30•73 | 4.50 (73,82) | 2465 (170) | 2755 (190) | 2900 (200) | 2500 | 350 | |
| PL. 30•82 | 4.98 (81,68) | 2320 (160) | 2465 (170) | 2610 (180) | 2200 | 350 | |
| PL. 30•90 | 5.56 (91,10) | 2175 (150) | 2320 (160) | 2465 (170) | 2200 | 350 | |
