**Specification range: A4VSG axial hydraulic pump 1x and 3x specifications range from 40 to 1000, with a variety of different displacement options.
**Rated working pressure: A4VSG plunger pump rated working pressure up to 350bar, peak pressure up to 400bar.
**Swash plate structure: adopts position control swash plate structure, can be adjusted steplessly, flow is reversible.
**Long life, low noise: long service life, can withstand axial and radial loads. Low noise level, smooth operation.
**Excellent weight / power ratio: The excellent weight / power ratio of A4VSG plunger pump makes it efficient and lightweight.
**Short control response time: short control response time, can quickly adjust flow and pressure.
**Through shaft structure: A4VSG piston pump is a through shaft structure, which can be composed of a combined pump, which is convenient for multiple pumps to be used in parallel.
**Equipped with a swash plate angle indicator: equipped with a swash plate angle indicator, which is convenient for observing and adjusting the swash plate angle.
A4VSG Axial hydraulic pump 1x And 3x:
A4VSG40,A4VSO71,A4VSO125,A4VSO180,A4VSO250,A4VSO355,A4VSO500,A4VSO750,A4VSO1000
| Size NG | 40 | 71 | 125 | 180 | 250 | 355 | 500 | 750 | 1000 | |
| Displacement,ย geometric, Vgย max
per revolution |
cm3 | 40 | 71 | 125 | 180 | 250 | 355 | 500 | 750 | 1000 |
| Rotational atย Vgย max nmax
speed maximum1) |
rpm | 3700 | 3200 | 2600 | 2400 | 2200 | 2000 | 1800 | 1600 | 1600 |
| Flow atย nmax qv
and Vgย max |
l/min | 148 | 227 | 325 | 432 | 550 | 710 | 900 | 1200 | 1600 |
| at 1500 rpm and Vgย max | 60 | 107 | 186 | 270 | 375 | 533 | 750 | 1125 | 1500 | |
| Power at nmax,ย Vgย max P
and ฮp = 350 bar |
kW | 86 | 132 | 190 | 252 | 321 | 414 | 525 | 700 | 933 |
| at 1500 rpm,
Vg max and ฮp = 350 bar |
35 | 62 | 109 | 158 | 219 | 311 | 438 | 656 | 875 | |
| Torque at Vgย maxย and M ฮp = 350 bar | Nm | 223 | 395 | 696 | 1002 | 1391 | 1976 | 2783 | 4174 | 5565 |
| at Vgย maxย and
ฮp = 100 bar |
64 | 113 | 199 | 286 | 398 | 564 | 795 | 1193 | 1590 | |
| Rotary P c | kNm/rad | 80 | 146 | 260 | 328 | 527 | 800 | 1145 | 1860 | 2730 |
| stiffnessย of Z c | kNm/rad | 77 | 146 | 263 | 332 | 543 | 770 | 1136 | 1812 | 2845 |
| Momentย ofย inertia JTW
Rotary group |
kgm2 | 0.0049 | 0.0121 | 0.03 | 0,055 | 0.0959 | 0.19 | 0.3325 | 0.66 | 1.20 |
| Maximum angular acceleration2) ฮฑ | rad/sยฒ | 17000 | 11000 | 8000 | 6800 | 4800 | 3600 | 2800 | 2000 | 1450 |
| Caseย volume V | l | 2 | 2.5 | 5 | 4 | 10 | 8 | 14 | 19 | 27 |
| Weightย approx. m | kg | 42 | 60 | 107 | 112 | 220 | 235 | 335 | 500 | 644 |
At POOCCA Hydraulic Manufacturers, we adhere to strict specifications throughout the entire manufacturing process, from material selection to production and testing. We select high-quality raw materials to ensure product performance and reliability. During the production process, each stage is strictly controlled to maintain quality and precision. Our products undergo rigorous testing, including visual inspection, dimensional measurement, and performance testing to ensure that they meet relevant standards and requirements. POOCCA Hydraulic Manufacturers is committed to providing high-quality, reliable hydraulic products that meet customer needs.
You can choose the packaging you need for transportation, and we will provide you with good packaging to protect our products to ensure they are intact.
We poocca have many new or old customers, and their evaluations of us are as shown in the screenshot. Because of high quality, affordable price, fast delivery, considerate service, etc., they gave extremely high evaluations to us. Feel very happy. Choosing poocca will provide you with economical and efficient benefits. Send your request and contact poocca immediately.
